ePropulsion E-Series Battery is a lithium iron phosphate battery with good safety perfor- mance, high energy density, long cycle life and high reliability.E-Series Battery includes two models, E60 and E163, with a nominal voltage of 51.2V and a capacity of 60Ah and 163Ah.
The intelligent battery management system (BMS) is applied to provide maximum safety for the users.
3,000 cycles at 80% DOD, the E-Series lifepo4 batteries power your motors much longer than lead-acid batteries.*
*Under equal capacity.
3 times higher energy density and 70% less weight than lead-acid batteries.*
*Under equal capacity.
E163 (single battery) can support Navy 6.0 Evo (9.9HP) full power output.
The height of E60 battery is only 300 mm, allowing flexible installation under the boat seat or other available spaces.
All-metal housing is more reliable, weather resistant, impact resistant and drop proof.
| Capacity | 8345 Wh / 163 Ah |
| Rated Voltage | 51.2 V |
| Battery Life | 3,000 cycles at 80% DOD |
| Weight | 76 kg |
| Dimensions | 470 x 295 x 495 mm (18.5 x 11.6 x 19.5 in) |
| Cut-off Voltage | 41.6 V |
| Final Charging Voltage | 57.6 V |
| Max Continuous Discharging Current | 150 A |
| Serial Connection | N/A |
| Parallel Connection | Up to 16 |
| Cell Configuration | 16S1P |
| Charger | E-Series battery charger |
| Charging Time (110V) | One charger: 11 Hrs Two chargers in parallel: 5.4 Hrs |
| Charging Temperature | 0 ~ 55℃ (32 ~ 131˚F) |
| Discharging Temperature | -10 ~ 60℃ (14 ~ 140˚F) |
| Communication | Available: CAN-Bus for Parallel RS485 for ePropulsion motors |
| Shipping Classification | UN3480, Class 9, UN38.3 Certified |
| Approvals | CE, UKCA, FCC |
| Warranty (Non-Commercial Use) | 2 years |
